Fully Automatic Lightweight Foamed Concrete Station

Brief Introduction

Introduction of HWF100 Fully Automatic Lightweight Foamed Concrete Station

Foam concrete specially made by foam concrete mixer is a kind of advanced lightweight and insulated material. This material has a great number of closed pores. With the help of the foaming system of the foaming machine, foam agents can foam fully and mechanically. Then foam and cement paste are mixed evenly. Next, the mixture will be out from the pumping system to cast in place construction or form mold. After natural conservation, foam concrete forms.

Features

Features and Advantages of HWF100 Fully Automatic Lightweight Foamed Concrete Station

Features

Lightweight:Dry density 400 kg/m^3 -1600kg/m^3 , 1/8-1/2 as light as common concrete.

High Compression Strength: Compression strength is ranging from 0.6 MPa to 25 MPa, 4 times as traditional aerated concrete.

Thermal Insulation: Good heat preservation and good thermal insulation.

Impermeability: Low water-intake rate and high impermeability.

Saving cost: Easy and fast production. No primary energy and reduced transportation costs.

Advantages

Beautiful:The shape is made of high-strength precision thickened steel plate, professional cover parts and sheet metal parts are manufactured and produced, and the appearance is beautiful.

Convenience:The whole container design is adopted, and the structure is compact, which is convenient for transportation, lifting, and construction.

High efficiency:The production capacity is as high as 70-100 cubic meters / hour.

Stable:The output of the slurry is even and stable, and the density of the finished foam concrete is uniform and the quality is stable.

Intelligent:Adopt automatic PLC intelligent control system, high-definition intelligent touch screen operation. The cement and water are fully and accurately weighed to achieve precise control of the water-cement ratio, thus controlling the bulk density of the foam concrete.

Parameters

Parameters of HWF100 Fully Automatic Lightweight Foamed Concrete Station

Model		HWF100
The actual output (m³/h)		70-100
Foam capacity(m³/h)		60-70
Foam concrete pump capacity(m³/h)		35
Max.pumping distance(m)	Horizontal	1000
	Vertical	110
Voltage		3 phase, 380V, 50Hz
Total motor power(kw)		54
Total weight (kg)		6000
Over dimension(mm)		4000×1810×2450

Shipping List:

No.	Name	Spec.	Unit	Qty.	Remarks
1	Foam concrete machine	HWF100	set	1
2	Conveyor	Φ273×6000	set	1
3	Delivery hoses	Φ76	pc	5	20m/pc
4	Water tank with holder		set	1
5	Steel tube	Φ76	pc	1	6m
6	Steel tube	Φ25	pc	2	6m
7	Suction tube		pc	1
8	Water pump	380V-5.5Kw	set	1
9	Waterproof poncho		pc	1
10	Work clothes		set	2
11	Dust bag		pc	2	（Φ280×500）（Φ400×500）个
12	Tool box	1 set
13	Documents	Manual, packing list and warranty card.

Detail Part

Detail Part of HWF100 Fully Automatic Lightweight Foamed Concrete Station

Application

Application of HWF100 Fully Automatic Lightweight Foamed Concrete Station

Foam concrete has a wide range of applications, including external wall thermal insulation, thermal insulation roofing, thermal flooring, upstanding beam foundation ditches filling, sound insulation and fire protection walls, playground and track construction, sound insulation layer and tunnel lining filling, cellar, basement and arch filling, sewers and drains filling, horizontal floor heightening, water tank and fuel tank building, platform filling and mending, garden and rockeries, foam concrete block, and foamed concrete precast hollow wallboard casting.
