HWGP440/50PI-22E High Pressure Horizontal Grouting Pump

HWGP440/50PI-22E High pressure horizontal grouting pump is a horizontal three-cylinder reciprocating single-acting piston pump. The power of the 22Kw motor is provided to the gearbox through a belt drive, and the mature and reliable frequency converter drives the gearbox. They are widely used in mining, geological drilling, railways, highways, water conservancy and hydropower, bridges, high-rise buildings, foundation reinforcement, and other projects.
Power:22 Kw
Pump speed:214 r/min
Max. Output:440 L/min
Max. Pressure:5 MPa
Size(L×W×H):2050*1370*1310 mm
Share With:
Brief Introduction
Features
Parameters;
Detail Part
Application
Shipping
Related
Inquiry
Brief Introduction
Introduction of HWGP440/50PI-22E High Pressure Horizontal Grouting Pump
HWGP440/50PI-22E High pressure horizontal grouting pump adopts a mature and reliable frequency converter, which has the characteristics of safety, energy saving, and convenient operation and maintenance. At the same time, it adopts advanced artificial intelligence control to realize the display and control of pressure and has the functions of instantaneous flow display and accumulation. In addition, the integrated design of the crankcase and gearbox is adopted, so the pump is not only reliable in performance and long in service life, but also small in size, light in weight, good in decomposition, and easy to move.
Features
Features of HWGP440/50PI-22E High Pressure Horizontal Grouting Pump
High Pressure Horizontal Grouting Pump
Can be removed from the base for maintenance
Open door in the important part to facilitate gearbox maintenance
Design with blinds, convenient heat dissipation
Power 22Kw motor to the gearbox by a belt drive
Mature and reliable frequency converter speed regulating drive
Using inclined gear transmission, stable, safe, and reliable operation
Crankcase and gearbox integrated design, so reliable operation, long service life, and small volume and lightweight
High Pressure Horizontal Grouting Pump
Has 3 water tanks separated from each other, and the three cylinders have a common suction chamber and a drainage chamber
The piston is a bowl-shaped nylon self-sealed S polyurethane rubber piston to improve the service life
It is provided with five dust seals on the pull rod to prevent the hydraulic mud from coming into the power end and the lubricating oil filter
Relief Valve: When the pressure exceeds the allowable pressure, the overflow valve will automatically open and the working cylinder will stop working
Control system (safe, and easy to operate)
Parameters
Parameters of HWGP440/50PI-22E High Pressure Horizontal Grouting Pump
Specification :
 Mode  HWGP440/50PI-22E GROUT PUMP
Modality Horizontal three-cylinder reciprocating single-action piston pump
 Cylinder diameter (mm) 100  Cylinder stroke (mm) 110
Power (Kw) 22 Pump speed (r/min) 214
Max. Output (L/min) 440 Max. Pressure (MPa) 5
Inlet  diameter (mm) 89 Outlet  diameter (mm) DN40
Size(L×W×H) (mm), Weight (Kg)        2050*1370*1310, 1365
Data: 1. All data are tested by water.
     2. We can customize products according to your requirements.
Detail Part
Detail Part of HWGP440/50PI-22E High Pressure Horizontal Grouting Pump
Application
Application of HWGP440/50PI-22E High Pressure Horizontal Grouting Pump
HWGP440/50PI-22E High pressure horizontal grouting pump provides high-pressure power for high-pressure jet grouting, which is used to reinforce the grouting of soft foundations such as new buildings, expressways, high-speed railways, and underground railways. It is also used in uneven settlement treatment of old buildings, deep protective curtains, earth retaining cofferdams, mine leakage prevention, well protection arm, slope anchorage, reservoir dam, and underground construction engineering.
