HWCP15H-E Versatile Squeeze Tube Pump is an industrial-grade hose pump engineered for high-pressure transfer of abrasive slurries, concrete mixtures, and corrosive media containing coarse particles. With an output capacity of 15m³/h and working pressure of 2.5MPa, it ensures stable performance in long-distance or vertical pumping operations, delivering consistent efficiency for demanding industrial workflows.
Introduction of HWCP15H-E Versatile Squeeze Tube Pump
HWCP15H-E Versatile Squeeze Tube Pump is equipped with a wear-resistant hose with an inner diameter of 75 mm, which can handle coarse aggregate concrete or mining mud without clogging. It is driven by a 22kW high-efficiency motor at the speed of 37rpm, which realizes smooth and low pulsation flow and reduces energy consumption and mechanical wear.
The HWCP15H-E Versatile Squeeze Tube Pump is durable and easy to maintain, with the function of tool-free hose replacement and built-in overload protection, which can ensure the safety during high load operation. Customizable options such as explosion-proof motor.
Features
Features of HWCP15H-E Versatile Squeeze Tube Pump
HWCP15H-E Versatile Squeeze Tube Pump
Compact Design： Integrated pump, mixer & hydraulic drive on one base.
Smart Hydraulic Drive： Stepless speed control with plug-and-play power unit.
Quick-Change Hose： Only wear part, <5 min replacement.
Parameters of HWCP15H-E Versatile Squeeze Tube Pump
Model
HWCP15H-E
Output Capacity
15m3/h
Working Pressure
2.5Mpa
Rotate Speed
37rpm
Squeeze Hose ID
75mm
Motor Power
22Kw
Switzerland client use it for pumping concrete.
Detail Part
Detail Part of HWCP15H-E Versatile Squeeze Tube Pump
Application
Application of HWCP15H-E Versatile Squeeze Tube Pump
HWH series peristaltic hose pumps are mainly used for long-distance transportation, metering pump delivery, pressure grouting and spraying of viscous mud in construction, underground engineering, mining, textile, papermaking, water treatment, ceramics and other fields.
If you are looking for related products or have any otherquestions please feel free to contact us.You can also give us a messagebelow , we will be enthusiastic for your service.
